CPU: 64-bit "Emotion Engine" clocked at 294.912 MHz (299 MHz on newer versions), 10.5 million transistors
System memory: 32 MB Direct Rambus or RDRAM
Memory bus Bandwidth: 3.2 gigabytes per second
Main processor: MIPS R5900 CPU core, 64-bit, little endian (mipsel).
Coprocessor: FPU (Floating Point Multiply Accumulator × 1, Floating Point Divider × 1)
Vector Units: VU0 and VU1 (Floating Point Multiply Accumulator × 9, Floating Point Divider × 1), 32-bit, at 147.456 MHz.
VU0 typically used for polygon transformations optionally (under parallel or serial connection), physics and other gameplay based things
VU1 typically used for polygon transformations, lighting and other visual based calculations (Texture matrix able for 2 coordinates (UV/ST)[53])
Parallel: Results of VU0/FPU sent as another display list via MFIFO (E.G. complex characters/vehicles/etc.)
Serial: Results of VU0/FPU sent to VU1 (via 3 methods) and can act as an optional geometry pre-processor that does all base work to update the scene every frame (E.G. camera, perspective, boning and laws of movement such as animations or physics)
Floating Point Performance: 6.2 GFLOPS (single precision 32-bit floating point)
FPU 0.64 GFLOPS
VU0 2.44 GFLOPS
VU1 3.08 GFLOPS (with Internal 0.64 GFLOPS EFU)
Tri-Strip Geometric transformation (VU0+VU1): 150 million polygons per second
3D CG Geometric transformation with raw 3D perspective operations (VU0+VU1): 66-80+ million polygons per second
3D CG Geometric transformations at peak bones/movements/effects (textures)/lights (VU0+VU1, parallel or series): 15–20 million polygons per second
Actual real-world polygons (per frame):500-650k at 30fps, 250-325k at 60fps
Compressed Image Decoder: MPEG-2
I/O Processor interconnection: Remote Procedure Call over a serial link, DMA controller for bulk transfer
Cache memory: Instruction: 16 KB, Data: 8 KB + 16 KB (ScrP)

Graphics processing unit: "Graphics Synthesizer" clocked at 147.456 MHz
Pixel pipelines: 16
Video output resolution: variable from 256×224 to 1920×1080 pixels
4 MB Embedded DRAM video memory bandwidth at 48 gigabytes per second (main system 32 MB can be dedicated into VRAM for off-screen materials)
Texture buffer bandwidth: 9.6 GB/s
Frame buffer bandwidth: 38.4 GB/s
DRAM Bus width: 2560-bit (composed of three independent buses: 1024-bit write, 1024-bit read, 512-bit read/write)
Pixel configuration: RGB: Alpha:Z Buffer (24:8, 15:1 for RGB, 16, 24, or 32-bit Z buffer)
Dedicated connection to: Main CPU and VU1
Overall pixel fillrate: 16×147 = 2.352 Gpixel/s (rounded to 2.4 Gpixel/s)
Pixel fillrate: with no texture, flat shaded 2.4 (75,000,000 32pixel raster triangles)
Pixel fillrate: with 1 full texture (Diffuse Map), Gouraud shaded 1.2 (37,750,000 32-bit pixel raster triangles)
Pixel fillrate: with 2 full textures (Diffuse map + specular or alpha or other), Gouraud shaded 0.6 (18,750,000 32-bit pixel raster triangles)
GS effects: AAx2 (poly sorting required), Bilinear, Trilinear, Multi-pass, Palletizing (4-bit = 6:1 ratio, 8-bit = 3:1)
Multi-pass rendering ability
Four passes = 300 Mpixel/s (300 Mpixels/s divided by 32 pixels = 9,375,000 triangles/s lost every four passes)
Audio: "SPU1+SPU2" (SPU1 is actually the CPU clocked at 8 MHz)
Sound Memory: 2 MB
Number of voices: 48 hardware channels of ADPCM on SPU2 plus software-mixed channels
Sampling Frequency: 44.1 kHz or 48 kHz (selectable)
Output: Dolby Digital 5.1 Surround sound, DTS (Full motion video only), later games achieved analog 5.1 surround during gameplay through Dolby Pro Logic II

To answer your responses:

Wally: It is not dead, there is just few developers just like the PSP. There is still new releases coming out for homebrew and such.

PSPdemon: Um, I know what you are thinking. The PS2 does have the PS1 hardware and BIOS in it, but when you use them, it only enables use from the CD drive and memory card/controller ports. There is a PS1 emulator that is used to play games from USB, Internal HDD, and Network here: http://psx-scene.com/forums/f292/ps2psx ... es-105355/

Lately, the forums on that have been more popular than these forums. I believe development ended a short time ago because the dev got uninterested, but I've heard that a new dev want to compile and work on the code.

Amin0152: I don't know what you are talking about, as there was no N64 emulator on PS2 at any point of time. Post a link and I'll see.


I've noticed that the clock for the CPU on DaedalusX64 is set at 279MHz by default (I don't know why not the full 333MHz, to save power?), so that means the PS2 EE has a faster core but I don't know a lot about the PS2 EE to know if it is more powerful.

Technically it's not overclocking, but I already have mine set 333MHz by default. If you have PRO HEN, then you can just press select and change the default clock speed ingame to 333MHz. The speed does go up, I was playing Pokemon Stadium 2 at default the clock and async sound and the announcer was really lagging, but then I changed it to 333MHz and the voice didn't lag as badly, it also went considerably faster.

I actually realized that it wasn't 333MHz by default today, I used the plugin Game Menu by neur0n to see if the default ingame was 333MHz and was surprised that it wasn't.

To answer your responses:

Wally: It is not dead, there is just few developers just like the PSP. There is still new releases coming out for homebrew and such.

I've noticed that the clock for the CPU on DaedalusX64 is set at 279MHz by default (I don't know why not the full 333MHz, to save power?), so that means the PS2 EE has a faster core but I don't know a lot about the PS2 EE to know if it is more powerful.
